Tank 300 CC2030BE21A 2302200XKM01A Front gearbox assembly EPC Diagram
EPC summary
This EPC diagram covers 2302200XKM01A Front gearbox assembly for Tank 300 model CC2030BE21A under F1600 Transmission system. It lists 13 OE part rows with quantities, rule notes, product links, and checkout options where available.
- Series
- Tank 300
- Model code
- CC2030BE21A
- Category
- F1600 Transmission system
- Diagram
- 2302200XKM01A Front gearbox assembly
- Parts count
- 13
- Product links
- 13
- Top OE numbers
- 2302101-K85, 2302407XKM01A, 2302130-K01, 2402023-D01, 2302700XKV73A, 2400601XPW01A, 2302500XKV09B, Q186U1255TFDE
Use this EPC page as a compatibility reference. Confirm the OE number, vehicle model code, and VIN before ordering.
Parts with product links open WooCommerce product pages for price, images, shipping, returns, and checkout.
| Callout | Photo | Part number | Name | Qty | Rule | Dates | Price | Action |
|---|---|---|---|---|---|---|---|---|
| 1 | 2302101-K85 | Nut - Fastening the drive bevel gear | 1 | 2022-04-28 | $23.50 | ProductAdd | ||
| 2 | 2302407XKM01A | flange and dust cover assembly | 1 | 2022-04-28 | $252.34 | ProductAdd | ||
| 3 | 2302130-K01 | Oil seal - front drive drive bevel gear | 1 | 2022-04-28 | $60.12 | ProductAdd | ||
| 4 | 2402023-D01 | Oil baffle plate - drive bevel gear oil seal | 1 | 2022-04-28 | $9.75 | ProductAdd | ||
| 5 | 2302700XKV73A | Left half shaft oil seal | 1 | 2022-04-28 | $69.66 | ProductAdd | ||
| 6 | 2400601XPW01A | Vent valve assembly | 1 | 2022-04-28 | $14.25 | ProductAdd | ||
| 7 | 2302500XKV09B | Long half-shaft oil seal assembly | 1 | 2022-04-28 | $36.72 | ProductAdd | ||
| 8 | Q186U1255TFDE | Hexagonal flange bolts | 2 | 2022-04-28 | $14.25 | ProductAdd | ||
| 9 | 2302405XPW01A | Front main suspension mount assembly | 1 | 2022-04-28 | $238.85 | ProductAdd | ||
| 10 | 2302103XPW01A | Front main reducer rear bushing assembly | 1 | 2022-04-28 | $184.91 | ProductAdd | ||
| 11 | Q184U1235TFDE | Hexagonal flange bolts | 2 | 2022-04-28 | $5.75 | ProductAdd | ||
| 12 | 2302114XKW09A | oil drain plug | 1 | 2022-04-28 | $20.52 | ProductAdd | ||
| 13 | 2302113XKW09A | Add fuel | 1 | 2022-04-28 | $19.00 | ProductAdd |
Compatibility FAQ
What vehicle does this EPC diagram apply to?
This EPC reference is for Tank 300 CC2030BE21A in the F1600 Transmission system catalog area.
What parts are included in this EPC diagram?
The page lists 13 OE part rows for 2302200XKM01A Front gearbox assembly, including callout numbers, part numbers, names, quantities, and rule notes when available.
How do I verify compatibility before ordering?
Compare the OE number, callout, model code, and VIN before ordering. Contact support if the VIN or OE reference does not match.
Can I buy the listed OE parts online?
13 listed part numbers currently link to WooCommerce product pages for price, images, shipping, returns, and checkout.
What should I do if my VIN or OE number does not match?
Do not rely on the diagram alone. Send the VIN, OE number, and required part position so compatibility can be checked before purchase.
